Vibration sensor AM3100

Description

The accelerometers in this sensor series offer a number offeatures making them well suited for harsh industrialenvironments and installation in locations with limited available space.

These case-mounted accelerometers provide accelerationmeasurements in units of g or m/s^2. The sensor has astandardized output voltage proportional to the level ofacceleration which can interface to a variety of conditionmonitoring solutions.

The range of vibration frequencies detected by these sensorsspans from 0.2 – 14,000 Hz.

Features

  l Rugged satainless design, corrosion resistant

  l Hermetic seal, case isolated

  l ESD protection

  l Reverse wiring protection

  l EMI / RFI shielded

  l Hazardous area certifications

Benefits

  l Able to fit in small spaces

  l Light weight for walk around programs

  l Cross wiring will not harm sensor

  l Prevents ground loops in permanent mount applications

  l Can be hosed down or submersed with proper connector

  l Can be used in applicable certified hazardous areas

Compliance

  l See individual accelerometers for compliance.

Ordering Information

Accelerometer Part Number

AM3100T2-Z2 Top exit sensor, 100 mV/g, Zone 2 rated

AS3100S2-Z2 Side exit sensor, 100 mV/g, Zone 2 rated

AP3500S2-Z1 Side exit sensor, 500 mV/g, Zone 1 rated

AP3500T2-Z1 Top exit sensor, 500 mV/g, Zone 1 rated

AS3100S2-Z0 Side exit sensor, 100 mV/g, Zone 0 rated

AM3100T2-Z0 Top exit sensor, 100 mV/g, Zone 0 rated
